Soft Rubber Module Flexible LED Display for any creative shape and size, which could be convex, concave or Twisted Available Module. Magnetic Connection for easy Maintenance.
Specification:
Soft Ribbon Rubber:
Durable solt rubber module, anti-static electricity
Soft PCB and rubber material
Integrated SMD,IC,Circuit for easy maintenance and heat dissipation
Magnetic connection for easy maintenance
Parameters | | BS-2X | BS-3 |
| Physical Pitch | 2.5 mm | 3 mm |
| Pixel Configuration | SMD 2121 | SMD 2121 |
| Pixel Density | 160,000 pixels/m² | 111,111 pixels/m² |
| Module Dimensions(W*H)(mm) | 240*120 | 240*120 |
| Panel Dimensions(mm) | Customized | Customized |
| Physical Resolution of Module(W*H) | 96*48 | 80*40 |
| Average Power Consumption | 9 W | 10 W |
| Max Power Consumption | 12 W | 13 W |
| Hotizontal Viewing Angle | 160° | 160° |
| Vertical Viewing Angle | 140° | 140° |
| Refresh Rate | ＞1,920Hz | ＞1,920Hz |
Slim and Lightweight and Quiet
5mm thickness, space efficiency
0.18kg per module, shipping cost and installation cost saving
Fanless design
Creative and Customized Forms
For any convex,concave or twisted installations
Customized pixel pitched available for variable installations
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of
technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ
Q1:How to choose a proper led screen for your need?
A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?
Q2:Which pixel pitch should i choose?
A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).
Q3:Which control system should i choose?
A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
Product Tags:
|
|
9W SMD2121 1000 Nits P2.5 Cylinder Flexible LED Display Images
|
