360 Degree Folable LED Display Stage Hanging Backdrop Slim Advertising Board
Foldable LED Screen is breaking through the traditional rigid led display,it can 360 degree rotated,foldable led display is welcome the customers,because of its foldable structure,light weight,ultra thin,irregular shape avaliable and high pitch density.
Description:
Unique body design, slim, lightweight
Flexible and foldable, any irregular-shaped LED display is available
Reliable, built to the highest standards
Fast and easy to assemble, real tool-free installation
Parameters:
| | BF-6 | BF-7 | BF-10 |
| Physical Pitch | 6mm | 7.8mm | 10mm |
| Pixel Configuration | SMD 3528 | SMD 3528 / SMD 3535 | SMD 3528 |
| Pixel Density | 27,556 pixels/m² | 16,384 pixels/m² | 10,000 pixels/m² |
| United Size (mm) | 192 × 192 | 250 × 250 | 160 × 160 |
| Physical Resolution of Unit (W× H) | 32 × 32 | 32 × 32 | 16 × 16 |
| Weight(kg/m²) | ＜10 | ＜9 | ＜9 |
| Gray Scale | 16bit | 16bit | 16bit |
| Colours | 281trillion | 281trillion | 281trillion |
| Contrast Ratio | 2,000 : 1 / 4,000 : 1 | 2,000 : 1 / 4,000 : 1 | 2,000 : 1 / 4,000 : 1 |
| Average Power Consumtion | 150 / 310 W/m² | 90 / 200 W/m² | 110 W/m² |
| Max Power Consumption | 375 / 775 W/m² | 225 / 500 W/m² | 275 W/m² |
| Operating Temp/Humidity | -10℃- 60℃ / 10%-60% | -10℃- 60℃ / 10%-60% | -10℃- 60℃ / 10%-60% |
| Storage Temp/Humidity | -30℃- 60℃ / 10%-60% | -30℃- 60℃ / 10%-60% | -30℃-60℃ / 10%-60% |
| Refresh Rate | >1,920 Hz | >1,920 Hz | >1,920 Hz |
| Brightness | 2,000 / 4,000 nits | 1,500 / 6,000 nits | 1,500 nits |
| Foldable Angle | 360° | 360° | 360° |
| Max Length of Control Box | 6m | 8m | 4m |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front | Front |
| IP Rating (Front/Rear) | IP 43 / IP 54 | IP 43 / IP 54 | IP 43 / IP 54 |
| Scan Method | 1/16 Scan | 1/16 Scan | 1/16 Scan |
