Soft Module High Contrast Ratio Flexible Indoor LED Display Rubber LED Screen
Quick Detail
Concave,convex or twisted available module
For any creative shape and size,for unique installations
Magnetic connection for easy maintenance
Description
1. Small pixel pitch ensure good vision effect for closed view distance, friednly to eyes,
2. Black led lamp body, high contrast rate, high definition up 1080P
3. Wide view angle with 160° for horizontal and 140° for vertical, no strobe,no image distortion and color cast from different angle
4. SMD LED encapsulated technology make slim thickness and good heat dissipation, energy-saving
5. Dot to dot maintain, easy and quick maintenance, save maintenance cost
6. Small module size is easy for different screen sizes,Cylindrical screens with different diameters
7. Modules with magnetics combined for different shaped screens seamlessly
8. Widely used for different curved,Cylindrical screens with different screens as request
BS / Specification
| | BS-2 | BS-2X | BS-3 | BS-4 |
| Physical Pitch | 2mm | 2.5mm | 3mm | 4mm |
| Pixel Configuration | SMD1515 | SMD2121 | SMD2121 | SMD2121 |
| Pixel Density | 250,000 pixels/sqm | 160,000 pixels/sqm | 111,111 pixels/sqm | 62,500 pixels/sqm |
| Module Dimension(W*H)(mm) | 240*120 | 240*120 | 240*120 | 240*120 |
| Panel Dimensions(mm) | customized | customized | customized | customized |
| Physical Resolution of Module(W*H) | 120*60 | 96*48 | 80*40 | 60*30 |
| Weight | 8.2kg/sqm | 8.2kg/sqm | 8.2kg/sqm | 8.2kg/sqm |
| Processing | 16 bit | 16 bit | 16 bit | 16 bit |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrst Ratio | 4,000:1 | 4,000:1 | 4,000:1 | 4,000:1 |
| Average Power Cinsumption | 9W | 9W | 10W | 10W |
| Max Power Consumption | 12W | 12W | 13W | 13W |
| Brightness | >1,000nits | >1,000nits | >1,000nits | >1,500nits |
| Refresh Rate | >1,920Hz | >1,920Hz | >1,920Hz | >1,920Hz |
| Driving Method | 1/40 | 1/40 | 1/40 | 1/8 |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Vertical Viewing Angle | 140° | 140° | 140° | 140° |
| Servicing | Front | Front | Front | Front |
| IP Rating(Front/Rear) | IP40 | IP40 | IP40 | IP40 |
Product Features
Our Installation service includes :
Product solution design (Including Cabinet/Frame structure design)
Assembly, LED set-up and testing at our warehouse
Electricity diagram and solution/requirement design
Control system set up and design
Assembly,LED set-up and testing onsite
Transport & warehouse storage
Maintenance / Logistic
Case
Our Service
Packaging and Shipping
FAQ:
Q1: The warranty of your LED Display Board ?
A: We offer 2-3 year warranty for our different led display screen series, 100,000 hours life span for the led lamps, and lifetime technology support with 7/24 phone answering service if you have any problem with our led screen.
Q2: Whats your payment term? How long it takes to delivery?
A: We normally accept T/T and L/C,and other payment options is negotiable for your convenience. A 30% deposit is needed in advance, and the rest 70% be paid before delivery. Our average lead time is 15 days.
Q3: Can I have a sample order for led module?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Our Company
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION contains of experienced team leaders and each of them has been working in LED display industry over 10 years. All of our R&D, Production, Sales, Technical Support depts….are running efficiently and smoothly by our great team work, moreover, delivering qualified product and offering timely pre-after service are also assured by BAKO VISION team.
BAKO VISION product lines have include UHD fine pitch, I/O rental, I/O fixed install, transparent screen, advertising poster, foldable screen, flexible screen, curtain, floor LED, perimeter display… meanwhile, based on our experienced R&D team and comprehensive management, we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
BAKO VISION main markets are among America, Europe, Middle East and Asia, all of our products are certificated by RoHS,CCC,CE,FCC,ETL,UL. Standing firmly by quality, winning firmly by proficient, in the past years of development, BAKO VISION continuous growth and brand positioning are all relied onto the long term partnership with variety channel customers over 120+ countries.
